Veil Nebula Witchs Broom (NGC 6960)

Veil Nebula – Witchs Broom (NGC 6960)

In Astrophotography by Matt Shetzer

Veil Nebula – Witchs Broom (NGC 6960)

Click image for detailed view



The Witch’s Broom, a striking feature of the Western Veil Nebula, slices through the cosmos like a spectral trail of smoke. It stretches in a jagged arc, its filaments crackling with the faint glow of energized gases that have been drifting for millennia. From a distance, it seems almost weightless, suspended like a brushstroke on the dark canvas of space. Up close, though, its structure reveals a fierce complexity—tangled threads of glowing material twisted into graceful forms, tracing the invisible push of a shockwave long since passed.

This is a place where light and silence collide. The Witch’s Broom is a remnant of upheaval, forged in the heat and chaos of a dying star’s final cry. What remains is haunting—threads of oxygen and hydrogen, energized and luminous, floating as if held together by memory alone. It’s not just a shape in the sky, but a slow, silent burn that arcs across time. With every subtle flicker, it hints at the force that birthed it, like embers still glowing after the fire is gone, refusing to be forgotten.

There is something deeply poetic about its name, too. The “broom” evokes motion, as if this wisp of nebula is sweeping across the stars, gathering cosmic dust as it drifts. It’s both delicate and unyielding, its beauty wrapped in the knowledge that it came from destruction. To look at it is to feel both the scale of the universe and the passage of time compressed into a single, fragile strand. The Witch’s Broom doesn’t scream its story—it whispers it, in trails of light that dance silently through the void.



Object Veil Nebula – Witchs Broom (NGC 6960)
Link https://www.shetzers.com/veil-nebula-witchs-broom-ngc-6960/
Wiki Link https://en.wikipedia.org/wiki/Veil_Nebula
Hemisphere Northern
Constellation Cygnus
Other Names contained in image NGC 6960
Imaging telescopes or lenses Takahashi FSQ -106ED4
Imaging cameras QHY268M
Mounts Software Bisque Paramount MYT
Focal reducers None
Software Software Bisque The Sky X, N.I.N.A., PHD Lab PHD2, Viking,  PixInsight, Photoshop, Lightroom, StarSpikes
Filters Astrodon LRGB Gen2 E-Series Tru-Balance  36mm unmounted. Chroma Technology Narrowband 3nm Ha, SII, OIII – 36mm Unmounted
Accessories Moonlite NightCrawler 35 focuser, Maxdome II, Digital Loggers Pro Switch, Sky Alert Weather Station, Pegagsus Ultimate Powerbox v2, Starlight Xpress filter wheel.
Guiding Telescope or Lenses Orion 60mm Guide Scope
Guiding Camera ZWO ASI290MM Mini
Imaging Dates 6/16/22,7/8/22,7/9/22,8/17/22,8/18/22,8/23/22,8/24/22,8/29/22,8/30/22,8/31/22,9/1/22,9/2/22,9/3/22,9/4/22,9/5/22
Frames 2 Panels
Panel 1
Red: 8×180″ (0.24h) Gain 25, Photographic Mode, Temp -10C, Bin 1×1
Green: 10×180″ (0.5h) Gain 25, Photographic Mode, Temp -10C, Bin 1×1
Blue:10×180″ (0.5h) Gain 25, Photographic Mode, Temp -10C, Bin 1×1
Ha: 66×600″ (11.0h) Gain 60, High Gain Mode, Temp -10C, Bin 1×1
OII: 47×600″ (7.8h) Gain 60, High Gain Mode, Temp -10C, Bin 1×1

Panel 2
Red: 9×180″ (0.45h) Gain 25, Photographic Mode, Temp -10C, Bin 1×1
Green: 9×180″ (0.45h) Gain 25, Photographic Mode, Temp -10C, Bin 1×1
Blue:8×180″ (0.24h) Gain 25, Photographic Mode, Temp -10C, Bin 1×1
Ha: 57×600″ (9.5h) Gain 60, High Gain Mode, Temp -10C, Bin 1×1
OII: 49×600″ (8.1h) Gain 60, High Gain Mode, Temp -10C, Bin 1×1

Integration 38h 45m
Darks 50
Flats 20 per Filter
Flat Darks 40
Bortle Dark-Sky Scale: 2
RA center 311.88691
DEC center 30.86446
Pixel scale 3.76
Resolution 6280 x 4210
Locations Sirus 3.5m Observatory, Carbondale Colorado
Data source Backyard
Seeing Average
Post Processing Techniques PixInsight to Photoshop to Lightroom
Type HOO with RGB Stars
Veil Nebula – Witchs Broom (NGC 6960) was last modified: April 7th, 2025 by Matt Shetzer
